Fine sand cyclone extraction machine for sale

FOB Reference Price:Get Latest Price
US $2,300-9,800 / Set | 1 Set/Sets (Min. Order)
Supply Ability:
10 Set/Sets per Week
Port:
Shanghai,Qingdao
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China (Mainland)
Brand Name:
LZZG
Model Number:
LZ
After-sales Service Provided:
Overseas service center available
Application:
sand washing plant
Color:
blue,white
Condition:
new
Usage:
waste recycling,dewatering
market:
worldwide
Motor type:
AC
Filter media:
polyurethane screen
Name:
sand recycling&dewatering machine
Weight:
depends
Efficiency:
depends
Packaging & Delivery
Packaging Details
standard packing ,20 feets container
Delivery Time
Shipped in 7 days after payment
Product Description

Fine sand cyclone extraction machine for sale



No.6 sand recycling system(dehydration type sand recycling machine)

We successfully make No.6 sand recycling system machine as our LZZG brand, improve core technical, select new processing methods and absorb different sites working situation, we supply No.6 sand recycling system which also called as “de-watering type sand recycling system”.

Working principle:

No.6 sand recycling machine, we still choose polyurethane screen as its main screening part, check its structure, we add recycling part on TS de-watering screen; sand after sand washer is fed onto polyurethane screen for de-watering waste sand water through steel chute or rubber pipe in water tank and extracted by slurry pump into high pressure sediment separator, fine sand 0.10-3mm is sprayed onto polyurethane screen also for de-watering, the waste water is back to return box and flowing out.

Features:

  1. Higher sand quality, lower moisture content
  2. Recycled fine size 0.10-3mm sand, lower mud content
  3. Compact structure and install easily
  4. Sand water content can be reduced to 10-15%



Specification:





Model

Slurry pump

Whirl cone

Polyurethane screen



Capacity (m³/h)



Weight (kg)

Power

(kw)

Material

Diameter (mm)

Size(m)

Square meter

Power (kw)

LZ12-55

15-22

Cr26

2*250

1.25*2.5

3.1

2*2.2

100-200

3.75

LZ12-65

    18.5-30

Cr26

2*300

1.25*2.5

3.1

2*2.2

120-250

4.25

LZ15-65

18.5-30

Cr26

2*300

1.5*3

4.5

2*3

150-275

5.15

LZ15-75

37-55

Cr26

2*350

1.5*3

4.5

2*3

180-350

5.65

             (Note:Specific design can be made based on different requirements.)

Application:

It is widely used in mud purification, artificial sand production line, hydropower stationand sand aggregate system, glass raw material processing system and coarse slime recovery, and fine material recovery.



woking site

FAQ

1.Is your product in stock?

Yes,once you place the order,the delivery will be done within one week.


2.Can the machine parts be replaced?

Yes,You can get them directly from us in a low price, and we make sure the easy maintainence and replacement .



3.How about your product performance?
Just look the picture and check for yourself.
Packaging & Shipping



Main body is wrapped with plastic sheet, spare parts are packed in wooden box.



Our Services

Market:worldwide

Technology: Engineers available to service machinery
Customized sizes:Specific design can be made based on different requirements.
Company Information



Main product:

Stone crusher:PE jaw crusher, PF impact crusher, PY spring cone crusher, HY hydraulic cone crusher, PC hammer crusher, PG roller crusher, etc.
Sand maker: VSI vertical impact crusher, PCL impact crusher
Sand washer: XSD sand washer, LSX spiral and washer, LZ sand washing & recycling machine, XS sand washing & dewatering machine



Powder mill: Raymond mill, YGM high pressure suspension mill, LSM ultra fine mill, PC hammer mill, Ball mill



Screening machine: YA vibrating screen, GP tailing dewatering screen, TS dewatering screen



Sand recycle machine: LZ sand recycling system. NO. 6 sand recycling machine.
